Product Details
- Size: 650*290*25
- Place of Origin: China
- Brand Name: DP-PV
- Model Number: 125
- Weight: 2.200 kg
| Characteristics | |
| Max Power Voltage Vmp (V) | 17.8V 18.2V |
| Max Power Current Imp (A) | 1.13A 1.38A |
| Open Circuit Voltage Voc (V) | 22.2V 22.4V |
| Short Circuit Current Isc (A) | 1.29A 1.61A |
| Max Power Pm (W) | 20W 25W |
| Temperature Coefficient of Cells | |
| NOCT 47℃±2℃ | |
| Temperature Coefficients of Isc (%/℃) | 0.06% |
| Temperature Coefficients of Voc (%/℃) | -0.33% |
| Temperature Coefficients of Pmp (%/℃) | -0.45% |
| Mechanical Data | |
| Typeof Cells(mm) | Mono125×31.25 |
| Dimension | 650×290×25mm |
| Weight | 2.2kg |
| NO. of Cells and Connections | 2×18=36 |
| The dimension of the modules can be changed according to the demand of clients | |
| Limits | |
| Operating Temperature | –45 °C to 80°C |
| Storage Temperature | –45 °C to 80°C |
| Max System Voltage | 700V |
| Guarantee | |
| Products Guarantee | 5yrs free from defects in materials and workmanship |
| Performance Guarantee | No less than 90% within 10yrs and no less than 80% within 20yrs |
| Certificates | IEC, ISO, CE,TUV |
